Platform Basket SPIDER 15.70 STD

Working height (mm)

14,500

Platform height (mm)

12,500

Outlay (mm)

6,500

Lifting capacity (kg)

230

Weight (kg)

1,950

Platform width (mm)

1,500

Platform length (mm)

700

Rotation chassis (degrees)

360

Weight (kg)

1,950

Construction height (mm)

1,999

Length (mm)

4,674

Width (mm)

790

Lifting capacity (kg)

230

Steering

Skidsteer

Electric equipment

230V to the platform

Wheel / undercarriage

4 stabilizers
Variable undercarriage

Wheel / undercarriage

Extra charge for non-marking tracks in substitution of the std black tracks
Set of 4 square nylon plates kit (40x40cm) with recovery frame.

Other equipment

Air outlet into the basket
Water outlet into the basket

Transmission

Hydrostatisk

Engine brand

Honda

Engine type

IGX390

Engine (hk)

12

Electric motor (V)

230V ac / 50hz

Electric motor (Ah)

3

Platform height (mm)

12,500

Outlay (mm)

6,500

Outlay height (mm)

5,500

Rotation chassis (degrees)

360

Platform width (mm)

1,500

Platform length (mm)

700

Driving speed (km/h)

2,0

Gradeability (%)

18

Permissible leveling (degrees)

18

Working height (mm)

14,500

Engine

Honda/IGX390

CustomFuelSource

Benzin

Datablad

Spider 15.70.pdf
