Platform Basket Heron 10 E

Working height (mm)

9,600

Platform height (mm)

7,600

Lifting capacity (kg)

230

Battery (V/Ah)

48 dc/210

Platform width (mm)

1,200

Platform length (mm)

870

Rotation chassis (degrees)

360

Weight (kg)

2,800

Construction height (mm)

1,990

Length (mm)

3,250

Width (mm)

1,200

Lifting capacity (kg)

230

Steering

Skidsteer

Electric equipment

230V to the platform
Radio remote control

Wheel / undercarriage

4 stabilizers

Transmission

Hydrostatisk

Electric motor (V)

200Ah/48Vdc

Electric motor (Ah)

4

Undercarriage

Non-marking tracks in substitution of the std black tracks

Battery (V)

48 dc

Battery (Ah)

210

Platform height (mm)

7,600

Rotation chassis (degrees)

360

Rotation basket (degrees)

140

Platform width (mm)

1,200

Platform length (mm)

870

Driving speed (km/h)

2, 8/1

Gradeability (%)

35

Working height (mm)

9,600

Battery other

Lithium battery

Battery (V/Ah)

48 dc/210

Brochure

Heron 10.pdf
