Platform Basket Heron 10 STD

Working height (mm)

9,600

Platform height (mm)

7,600

Lifting capacity (kg)

230

Platform width (mm)

1,200

Platform length (mm)

870

Rotation chassis (degrees)

360

Weight (kg)

2,750

Construction height (mm)

1,990

Length (mm)

3,250

Width (mm)

1,200

Lifting capacity (kg)

230

Steering

Skidsteer

Electric equipment

Radio remote control
220/110V i kurv

Wheel / undercarriage

4 stabilizers

Other equipment

Elektrisk motor 230V/50Hz (3 HK/2
2kW)

Engine brand

Kubota

Power Source

Diesel

Engine (hk)

13

Engine (kW)

10

Undercarriage

Non-marking tracks in substitution of the std black tracks

Battery (V)

12V

Platform height (mm)

7,600

Rotation chassis (degrees)

360

Rotation basket (degrees)

140

Platform width (mm)

1,200

Platform length (mm)

870

Driving speed (km/h)

2, 8/1

Gradeability (%)

35

Working height (mm)

9,600

Brochure

Heron 10.pdf
