Manitou 150AETJ C 3D 48V

Working height (mm)

15,000

Platform height (mm)

13,000

Outlay (mm)

7,600

Lifting capacity (kg)

200

Platform width (mm)

920

Platform length (mm)

1,200

Rotation chassis (degrees)

355

Weight (kg)

6,700

Construction height (mm)

1,970

Length (mm)

6,050

Width (mm)

1,500

Lifting capacity (kg)

200

Electric equipment

230 V European type electric plug with differential circuit breaker

Security

Secondary Protection System (SPS) with red flashing light

Other equipment

Easy link
Painted basket 1.20 m

Wheel front type

Non-marking rubber tyres 600 x 190 mm / 24 x 7 in

Wheel rear type

Non-marking rubber tyres 600 x 190 mm / 24 x 7 in

Battery (V)

lead battery EXIDE/GNB 2x24V / 240 Ah

Platform height (mm)

13,000

Outlay (mm)

7,600

Outlay height (mm)

7,000

Rotation chassis (degrees)

355

Rotation basket (degrees)

140

Rotation jib (degrees)

140

Tilt jib (degrees)

140

Platform width (mm)

920

Platform length (mm)

1,200

Wheelbase (mm)

2,000

Free height (mm)

140

Driving speed (km/h)

5

Gradeability (%)

22

Permissible leveling (degrees)

3

Working height (mm)

15,000

Battery other

Built-in charger

Datablad

150AETJ-C_datablad.pdf
