Manitou 180ATJ E RC

Working height (mm)

18,190

Platform height (mm)

16,190

Outlay (mm)

10,510

Lifting capacity (kg)

230

Platform width (mm)

1,800

Platform length (mm)

800

Rotation chassis (degrees)

360

Weight (kg)

7,430

Construction height (mm)

2,470

Length (mm)

5,560

Width (mm)

2,320

Lifting capacity (kg)

230

Steering

4 wheel steering

Electric equipment

230 V European type electric plug with differential circuit breaker

Light equipment

Rotating beacon

Security

Secondary Protection System (SPS) with red flashing light

Other equipment

Continuous rotation

Other equipment

Easy link
Galvanized basket 2.10 m with lateral door

Wheel front type

Non-marking foam filled tyres 910 x 370 mm / 36X15D610

Wheel rear type

Non-marking foam filled tyres 910 x 370 mm / 36X15D610

Battery (V)

lead battery EXIDE/GNB with centralised filling 48V-480Ah

Platform height (mm)

16,190

Outlay (mm)

10,510

Outlay height (mm)

7,550

Rotation chassis (degrees)

360

Rotation basket (degrees)

180

Tilt jib (degrees)

125

Platform width (mm)

1,800

Platform length (mm)

800

Wheelbase (mm)

2,200

Free height (mm)

400

Driving speed (km/h)

5

Gradeability (%)

45

Permissible leveling (degrees)

5

Working height (mm)

18,190
